Product Description
Upgrade your axles, replace damaged axles, or build a trailer with this 14,000 lbs. Tandem Axle Tire Wheel trailer kit. This kit comes with all the necessary hardware to install both axles on your trailer and get you on the road. Kit also includes a set of 4 16" 10ply Tires and wheels mounted.
This 14k Rockwell Heavy Duty Tandem Axle Tire Wheel Trailer Kit Includes:
(2) 7000 lbs Electric Brake Trailer Axles Fully Assembled With 12" x 2" Electric Brake 8 lug 6.5" bolt pattern.
(4) 3.5k Slipper springs 5-leaf 26-7/8" I to End, 2" wide
(2) 3" u bolt kits (includes 4 u bolts, 2 tie plates and the locking nuts) One kit per axle.
(1) tandem hanger kit for slipper springs
(all hardware needed to install axles on trailer)
(4) 16" 10ply Tire wheel Combos
Select from the options above to get what you need today. If you do not see the option you need, give us a call, or fill out a custom axle order form, email or fax it to us for a quote.
Axle Components & Specs:
Brand: Rockwell American
Axle Inner Bearing – 25580
Axle Inner Race – 25520
Axle Outer Bearing - 14125A
Axle Outer Race - 14276
Axle Seal - 10-36
Axle Hub Drum - 8 lug 6.5" bolt pattern
Axle Beam - 3” Round tube 1⁄4” wall Thickness.
Axle Hub Cap - Posi Lube Grease
Axle Studs - 9/16”
Axle Brakes - 12” x 2” Electric
Replaces Dexter, AL-KO, Hayes,Lippert Axles, and Just about any other brand axle.
Trailer Axle Specifications:
Axles come fully assembled
12” x 2” Electric Brakes on both axle.
Axles are pre-wired in axle tube.
Packed with High-Temp Axle Grease.
Posi-Lube Design.
Zerk fitting on spindle use rubber plug on the hub cap to grease bearings simply.
Grease your axle without pulling off your whole entire hub.
Underslung – Axle is welded with spring seats on the bottom (Axle sits on top of the springs)
which Allows for lower ride height. For optimal usage, use with double eye springs
High Strength Cambered Steel Axle Tube Construction to ensure Even Tire Wear so the tires will last longer.
Powder coated black.
Great for Utility Trailer Axle, Boat Trailer Axle, Car Haulers Trailer Axle, ATV Trailer Axle, Lawn & Landscape Trailer Axle, Motorcycle Trailer Axle,
BBQ Pit Trailer Axle, Cargo Trailer Axle, Enclosed Trailer Axle, RV Trailer Axle & More.
Axles come fully assembled ready to install on your trailer.
This 2" wide 5 leaf slipper style spring is designed for 5,200 - 7,000 pound suspension systems.
Number of Leafs: 5.
Capacity: 3,500. Free Length: 26 7/8". Spring Width: 2".
Free Arch: 3-3/16". Bushing ID: 9/16".
Interchanges : 72-32 , UNA-232, SH-7232, 72-32, UNA-232, SH-7232, 5L-SS, 1203T3
3" Axle Tube U-bolt Kit for 5,200 - 7,000 lb Trailer Axles
kit includes:
(4) 1/2"-20 x 6.63" L 3" Tube U-bolts
(8) 1/2"-20 U-bolt nuts
(2) Tie Plates for 3" Wide Axle Tubing u bolts
(This Kit is all the u-bolts and hardware for one complete axle).
Tandem Axle Hanger Kit Specifications:
Tandem Axle Hanger Kit for 2" Wide Slipper Springs - 12" Long Equalizers.
Includes the following:
(2) 3" Wide front hangers.
(2) 3" Wide Rear Hangers.
(2) 3" wide center hangers.
(2) Equalizers 12" Long for slipper springs.
(8) 9/16" x 3-1/2" shackle bolts with 7/16"-20 threads.
(8) 7/16"-20 Flange Nuts - serrated.
(2) 7/8" x 4-11/16" equalizer bolts.
(2) 7/8" castle nuts.
(2) cotter pins.
ST235/80R16 10-Ply Radial Trailer Tire Specifications:
Tire Size: ST235/80R16
Ply Rating: 10
Load Range: E
Overall Diameter: 30.79”
Section Width: 9.25”
Max Capacity Per Tire: 3,520 lbs
Tire PSI: 80 lbs
16" Wheel Specs:
Wheel Size: 16” x 6”
Bolt Pattern: 8x6.5”
Center Bore Hole: 5.15”
Offset: 0
Max Load Per Wheel: 3,800 lbs
Offset: 5.35”
Wheel Style: Silver Modular
Wheel Material: Steel
Powder coated
How to properly measure your axle:
Hub Face (HF):
measure from one end of the axle where the lug bolts protrude out from to the other end at the same point. This is the Hub Face.
Spring Center (SC):
Measure from the middle of the spring on one axle to the center of the other spring on the same axle.
There should be about 15" difference between the Hub Face and the Spring Center measurement. (7-1/2" each side
How To Measure Your Bolt Pattern:
