This is a very common request we hear:
“I need a 74” spring center and around a 98” hub face.”
Sounds simple—but when you step into a 10K axle, the geometry doesn’t allow it.
The Rule Most People Don’t Know
On a 10K axle, you need a minimum of 26” difference between hub face and spring center.
- That equals 13” per side
- This spacing is required to properly fit:
- Larger 12-1/4” x 3-3/8” brakes
- Bigger hubs and drums
- Heavier spindle assemblies
There’s no way around this—it’s how these axles are built.
What Happens With a 74” Spring Center
If you have a 74” spring center, the shortest hub face you can realistically run on a 10K axle is about 100”.
So:
- Requested: 98” hub face
- Reality: ~100” minimum
That extra width matters more than people think.
Why This Becomes a Problem
This isn’t about fitment—it’s about legality.
Running a 100” hub face with a 74” spring center will push your setup over legal road width.
- Tires will stick out past the fenders
- You’ll be outside legal limits for highway use
- You’re opening yourself up to:
- DOT violations
- Fines
- Getting pulled over
If the trailer is off-road only, then it’s not a big deal.
But if you’re running on public roads, you’re taking a risk every time you tow it. If you’re willing to deal with the tickets and hassle, that’s on you—but you will be over width.
Simple Breakdown
- 74” spring center requires ~100” hub face on a 10K
- You cannot achieve 98” with that setup
- The result is a wider trailer that can put you outside legal limits
What Are Your Options?
If you’re trying to stay within a tighter width, here’s what actually works:
1. Stay with a lighter axle (7K or 8K)
Allows tighter hub face dimensions and is easier to match your current setup
2. Move your spring hangers
Adjusting hanger placement allows proper geometry for a 10K axle
3. Accept the wider setup
Only makes sense if the trailer won’t be used on public roads
Bottom Line
You can’t cheat axle geometry.
If you’re running a 74” spring center, a 98” hub face is not possible on a 10K axle. The required spacing forces you wider, and that can create real legal issues on the road.
